RSPdxR2

£188.00 ex. VATApproximately $254.43 (USD)

SKU: RSPdxR2 Categories: , Tag:

Description

If you are into MW Dxing or HF listening, then this is the device for you.  The RSPdxR2 is optimised for its LW and MW performance, its finer LNA control allows you to refine the performance sweet spot when signal hunting.  The High Dynamic Range (HDR) mode minimises internal receiver noise meaning you can pick out the weakest of signals next to the strongest stations.  With its multiple antenna inputs you can connect a range of antennas to cover your band of interest.  The additional low frequency filter options included means this is the go-to device for those demanding LW and MW listeners.

Additional information

Weight 0.315 kg
Dimensions 9.8 × 9.4 × 3.5 cm
Unique Features

HDR Mode for improved signal handling
(available in 0-500 kHz, 0-1750 kHz, 2200m, 630m, 160m, LW, MW, NDBL and NDBH bands)
Optimised for LW and MW performance
Additional Band filter for low frequency reception

Receiver Type

Single Tuner

Antenna Connector

2x SMA, 1x BNC

Frequency Coverage

1 kHz – 2 GHz continuous (SMA connectors)
1 kHz – 200 MHz continuous (BNC connector)

Band Filters

12 Band Filters

Additional Filters

AM/FM and DAB switchable Notch Filters

External Reference Input

24 MHz
1V Pk-Pk Minimum drive
3V Pk-Pk Maximum drive

Useable Temperature Range

-10C to +60C

Maximum Input Power

0dBm continuous
+10dBm Burst

Power

USB Powered

  1. Download & Install SDRconnect
  2. Connect the RSPdxR2 to the USB port of your host device
  3. Start SDRconnect and you'll see the device in the top left
  4. Press Play and start to tune around
